Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.
Timber Frame Screw WAFER A2 SS

Timber Frame Screw WAFER A2 SS - 8.0 x 100 (Tube 20)

SKU: 100INDEXWSST
£24.42 inc. VAT
£29.32 Sale £24.42 inc. VAT
Description

TIMCO Wafer Head A2 Stainless Steel Timber Screws - 8.0 x 100

Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.

Wafer head countersunk and TX40 recess

Stainless Steel offers superior corrosion resistance, perfect for highly corrosive environments

Helix shank for removing debris and to improve clamping

Single slash point to reduce torque and the risk of timber splitting at low edge distance

25 ° sharp point and single lead for a fast start and improved thread acceptance

Description Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.
Pack Quantity 20
Size mm 8.0 x 100
Driver Bit Size TX40
Thread Type Serrated
Substrates Hardwood, Softwood, Corrosive Wood (e.g. Oak, Cedar)
Product Code 100INDEXWSST
Point Type 25 ° Sharp with Single Slash
SKU Barcode 5056110836287
Thread Length mm 70
Shank Type Helix
Colour Silver
Pack Type Tube
Material Austenitic Stainless Steel (A2-304)
Pack Quantity Unit Pieces
Included Items TX40 S2 Bit (Qty 1)
Length mm 100
Recess Type TX Drive
Head Type Wafer
Thread Dia. mm 8
Corrosion Rating 4 - Urban & industrial areas with a moderate salt atmosphere
Fixed Washer Dia. mm 21
Head Dia. mm 20.84
CE Standard Web BS EN 14592:2008
Inner Thread Dia. mm 5.6
Carton Qty Packs 40
Carton Qty pcs 800
Pack Weight kg 0.58
Pack Dimensions L x W x H mm 58 x 58 x 138
Thread Coverage Partially Threaded
