Designed as an alternative to the traditional coach screw. This heavy duty screw dramatically decreases installation time as it doesn’t require a pilot hole into most wood types. This screw is ideal for external applications or where extra strength is required. Coated with a patented multi-layer corrosion resistant plating to withstand 1,000 hours salt spray test.
Timber Frame Screw HEX Silver

Timber Frame Screw HEX Silver - 10 x 160 (Bag 10)

SKU: 10160INI
£5.20 inc. VAT
£6.29 Sale £5.20 inc. VAT
Description

TIMCO Heavy Duty Timber Screws Hex Flange Head Exterior Silver - 10 x 160

Designed as an alternative to the traditional coach screw. This heavy duty screw dramatically decreases installation time as it doesn’t require a pilot hole into most wood types. This screw is ideal for external applications or where extra strength is required. Coated with a patented multi-layer corrosion resistant plating to withstand 1,000 hours salt spray test.

Hex head countersunk with a fixed washer

Patented silver corrosion resistant plating

50 ° deep single thread to provide a secure fixing with high pull-out resistance

Single slash point to reduce torque and the risk of timber splitting at low edge distance

Helix removes debris and helps improve clamping

SKU Barcode 5055893387436
Pack Quantity 10
Pack Type Bag
Product Code 10160INI
Description Designed as an alternative to the traditional coach screw. This heavy duty screw dramatically decreases installation time as it doesn’t require a pilot hole into most wood types. This screw is ideal for external applications or where extra strength is required. Coated with a patented multi-layer corrosion resistant plating to withstand 1,000 hours salt spray test.
Pack Quantity Unit Pieces
Corrosion Rating 3 - Urban & industrial areas with a low salt atmosphere
Included Items Socket Driver (Qty 1)
Material Carbon Steel
Finish Exterior (Silver Organic)
Shank Type Helix
Colour Silver
Length mm 160
Thread Length mm 60
Size mm 10.0 x 160
Thread Type 50 ° Single Deep
Head Type Hex Flange
Point Type 25 ° Sharp with Single Slash
CE Standard Web BS EN 14592:2008
Thread Dia. mm 10
Carton Qty pcs 50
Carton Qty Packs 5
Socket Size mm 13
Fixed Washer Dia. mm 18.11
Inner Thread Dia. mm 6.56
Pack Dimensions L x W x H mm 20 x 130 x 290
Pack Weight kg 0.66
Recess Type External Hex
Thread Coverage Partially Threaded
