C/Screw Hex W16 S/Drill BIMET - 5.5/6.3 x 100 (Box 100)
Regular price
£112.57
inc. VAT
Regular price
£135.18
Sale
Sale price
£112.57
inc. VAT
TIMCO Self-Drilling Light Section Composite Panel A2 Stainless Steel Bi-Metal Screws with EPDM Washer - 5.5/6.3 x 100
Specifically designed to attach composite panel to light section steel (Max. 5mm). Self-drilling point with hexagon head and split thread.
Hardened carbon steel drill tip fused on to an A2-304 Austenitic Stainless Steel body
| Product Code | BMLH100W16 |
| Pack Type | Box |
| Pack Quantity | 100 |
| Description | Specifically designed to attach composite panel to light section steel (Max. 5mm). Self-drilling point with hexagon head and split thread. |
| SKU Barcode | 5055893368879 |
| Fixed Washer Dia. mm | 12 |
| Effective Thread Length mm | 47 |
| Pack Quantity Unit | Pieces |
| Finish | Exterior (Silver Organic) |
| Material | Bi-Metal/A2-304 Stainless Steel/Carbon Steel |
| EPDM Washer mm | 16 |
| Substrates | Composite Panel |
| Corrosion Rating | 4 - Urban & industrial areas with a moderate salt atmosphere |
| Size mm | 5.5/6.3 x 100 |
| Head Type | Hex |
| Point Type | Self-Drilling No.3 |
| Length mm | 100 |
| Thread Type | Dual 60 ° Self-Tapping |
| Rec RPM | 1,000 - 1,800 |
| Min Max Panel Thickness mm | 50 - 80 |
| Thread Dia. mm | 5.5 - 6.3 |
| Carton Qty pcs | 900 |
| Carton Qty Packs | 9 |
| Socket Size mm | 8 |
| Drill Tip Length mm | 8.5 |
| Head Height mm | 5.3 |
| Max Drilling Thickness mm | 5 |
| Included Items | 16mm EPDM Washers |
| Type | For Light Section Composite Panel |
| Pack Dimensions L x W x H mm | 180 x 90 x 110 |
| Pack Weight kg | 1.63 |
| Thread Coverage | Partially Threaded |
