WingTip Screw S/DRILL No3 Zinc - 5.5 x 150 (Box 100)
Regular price
£24.33
inc. VAT
Regular price
£29.24
Sale
Sale price
£24.33
inc. VAT
TIMCO Self-Drilling Wing-Tip Steel to Timber Light Section Silver Screws - 5.5 x 150
Specifically designed to attach wood to light section steel (Max. 5mm). Coarse self-tapping thread with wings designed to ream out the timber, so the screw can achieve Max. R.P.M. without burning out. When the wings hit the metal they will break off to permit the thread to self-tap into the metal. NOTE: Partially threaded.
| Pack Quantity | 100 |
| Pack Type | Box |
| Description | Specifically designed to attach wood to light section steel (Max. 5mm). Coarse self-tapping thread with wings designed to ream out the timber, so the screw can achieve Max. R.P.M. without burning out. When the wings hit the metal they will break off to permit the thread to self-tap into the metal. NOTE: Partially threaded. |
| Product Code | LW150B |
| SKU Barcode | 5055331815309 |
| To Suit Timber mm | 109 - 128 |
| Max Fixture Thickness mm | 128 |
| Pack Quantity Unit | Pieces |
| Recess Type | Phillips |
| Finish | Zinc |
| Rec RPM | 1,000 - 1,800 |
| Material | Case & Core Hardened Carbon Steel |
| Corrosion Rating | 1 - Clean, dry & low humidity environments |
| Included Items | PH3 S2 Bit (Qty 1) |
| Substrates | Steel, Timber |
| Size mm | 5.5 x 150 |
| Head Type | Countersunk with Ribs |
| Driver Bit Size | PH3 |
| Thread Type | Coarse Self-Tapping, *P/T = Partially Threaded |
| Point Type | Self-Drilling No.3 |
| Length mm | 150 |
| Type | For Timber to Light Section Steel |
| Effective Thread Length mm | 61 *P/T |
| Thread Dia. mm | 5.5 |
| Carton Qty pcs | 1200 |
| Carton Qty Packs | 12 |
| Drill Tip Length mm | 15 |
| Max Drilling Thickness mm | 5 |
| Head Height mm | 5 |
| Head Dia. mm | 11 |
| Pack Dimensions L x W x H mm | 180 x 90 x 90 |
| Pack Weight kg | 1.938 |
| Thread Coverage | Partially Threaded |
